SMART ADAPTER W Specification・Components

Specification

Power Supply Voltage

DC10V～16V(For 12V vehicle)

Current Consumption

■Connection to ADVANCE SYSTEM
Maximum value in case 7 gauges are connected
+B line 2A(IGN ON), 5mA(IGN OFF)
ILM line 800mA

■Connection to OBDII
Maximum Current Consumption(SMART ADAPTER W)0.3A

Part names & Dimensions

SMART ADAPTER W dim

Part name	QTY	[DF14501] SMART ADAPTER W	[DF14502] SMART ADAPTER W OBD SET
SMART ADAPTER W	1pc	○	○
Double sided tape	1pc	○	○
Meter wire harness 25cm	1pc	○	○
Speed & Tachometer Signal Wire harness 2m	1pc	○	×
OBDII wire harness 20cm (SMART ADAPTER W only)	1pc	×	○
Adapter wire harness 80cm (SMART ADAPTER W only)	1pc	×	○
Cigar plug wire harness 1.5m	1pc	×	○
Tie wrap	3pc	×	○

※Adding to the above, including the operation manual and the warranty card in a package.
